Gbos High Performance Camera Capture CNC CO2 Laser Cutter Cutting Machines For Woven And Embroidery Label Logo

FOB Reference Price:Get Latest Price
$1,000.00 - $40,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
FB02CCD-90
Power(W):
≤90W
Lead Time:
Quantity(Sets) 1 - 5 >5
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood, Fabric, Label
Laser Type:
CO2
Cutting Area:
750mm X 580mm
Cutting Speed:
0-36000mm/min
Graphic Format Supported:
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, JPG
Application:
Laser Cutting
Applicable Industries:
Garment Shops, Label Industyr
Condition:
New
Cutting Thickness:
Depend on the materials
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Control Software:
GBOS LASER SYSTEMS
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
GBOS LASER
Certification:
CE, SGS, ISO, FDA
Warranty:
1 Year
Laser Source Brand:
GBOS
Laser Head Brand:
GBOS
Servo Motor Brand:
GBOS
Guiderail Brand:
GBOS
Control System Brand:
GBOS Control System
Key Selling Points:
Automatic and Feeding
Laser power:
90W
Color:
Red / White
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard Ply-wooden case for exporting, non fumigation.
Port
SHENZHEN / GUANGZHOU
Lead Time :
Quantity(Sets) 1 - 5 >5
Est. Time(days) 10 To be negotiated
Video Description
Product Description

GBOS High Performance Camera Capture CNC CO2 Laser Cutting Machine For Woven, Embroidery Label

Gbos CCD smart visual detection system is a smart visual control software which is researched and developed by GBOS in laser cutting system. Fabric printing patterns or feature points can be detected and positioned by software, which can be widely used in label, shoe, textile, garment, suitcase and other industries.

Gbos intelligent camera positioned laser label cutter is with the design of feeding and collecting. It meets various laser processes such as cutting off and feeding, layered cut, perforating, etc. Adopt camera positioning, automatic identification function, edge cutting effect, etc. With imported metal laser generator, high precision, fast speed.

GBOS High Performance Camera Capture CNC CO2 Laser Cutting Machine
MODEL
FB02CCD
Laser Power
≤90W
Processing Area(mm)
750×580mm
Gross Power
≈1500W
Measurement(mm)(L×W×H)
1750×1160×1310
System/Compatible Format
Windows XP/7/8/10, AI, PLT, DXF, DST, BMP, JPG , JPEG, PNA , TIF, etc
Weight(kg)
280KG
Power Supply
220V/10A,50Hz or 60Hz
CUTTING PRECISION
±0.2mm
CUTTING SPEED
0-36000mm/min
CAMERA PIXELS
1.3 million pixels
CAMERA VISION RANGE
120mm×90mm
Cutting Samples

GBOS Label Laser Cutting Machine applicable materials
woven label, printed label, heat transfer label, embroidery label, fabric, seamless pockets, seamless underwear, etc.

Product Advantage

Camera positioning and cutting

According material transformation condition,automatic deformation cutting
Camera follow the label transformation do grapth matching.
Solve the problem of cutting edge unsmooth.



Positioning cutting for any angle

Multi pattern, any angle positioning and cutting.



Automatically identifying defect

Defective products can be selected automatically.


Multi-design concurrent positioning cutting.

Positioning cutting for multiple design.


Cut off and feeding

No need pull by manual.


CCD Automatic extraction (Optional)

Effectively identify area: 120mm*90mm
Automatic tracking and cutting

Achieving border cutting effect.


Precise layered cutting.

Kiss cut the heat transfer label.


Ribbon cutting and automatically remove waste

Automatically collecting waste.


Rolling label auto-feeding device

For automatically feeding.


Deformation matching cutting

The cutting contour is adjusted according to the printing.
① Offset compensation.
② Deformation compensation.
③ Rotaion.
④ Linear compensation.


First choice for seamless artworks

Adopt metal laser generator, Maintenance-free, Long life(over 5 years), laser beam precision , more stable, can achieve no yellow or burn edge effect.


Free exchanging of two working table

① Feeding table for roll labels.
② Fixed size table for labels in piece.


Convenient collecting device

No need manual collecting.

Cutting Samples

GBOS Laser Label Cutting Machine applicable materials
woven label, printed label, heat transfer label, embroidery label, fabric, seamless pockets, seamless underwear, etc.

About GBOS
GBOS LASER INC. A national high-tech enterprise dedicated to provide laser intelligent solution globally.


Since it was established in 2005, GBOS Laser Brand has been devoted to the research and development, innovation, production and sales of medium and high-end laser systems. So far, it has launched more than 150 kinds of intelligent laser systems, and product lines cover laser marking, cutting, drilling, engraving and other fields. The company has passed the industry's ISO9001.2008 quality management standard and its core technology has won several national patents and software copyrights. A number of products have passed the EU CE certification and the U.S. FDA certification.


The company's core technology, talent, and innovation have created the most comprehensive product line of laser systems in the industry. As the industry leader in intelligent laser systems, our laser systems are being used in various countries and regions worldwide, and customers range from small family-owned businesses to large highly automated enterprises. We believe that our leading laser system can help you to develop and maintain a competitive advantage.

"All GBOS people will be proud of the well-known GBOS". We make every effort to create the world's leading brand in the laser industry.
Our Service

Pre-sales

✔Free sample testing
✔Professional introduction

✔Multilingual online services

✔Warranty available and prompt delivery

After-sales

✔Free technical training and software upgrading
✔Remote control and local installation
✔Machine maintenance

Exhibition



GUANGZHOU CHINA SHOES MATERIAL MACHINARY FAIR

Located in Guangzhou




SIMAC &TANNING-TECH INTERNATIONAL EXHIBITION OF MACHINES AND TECHNOLOGIES FOR FOOTWEAR AND LEATHERGOODS AND TANNING INDU

Located in Italy


CHINA INT'L SEWING MACHINERY & ACCESSORIES SHOW

Located in Shanghai






VIETNAM SAIGON TEXTILE&GARMENT INDUSTRY FABRIC&GARMENT ACCESSORIES EXPO
Located in Vienam

FAQ

Q1:What's the cutting precision of laser cutting machine?
±0.2mm, the best in the industry.

Q2: How to cut the label by laser cutting machine?
There are two kinds of cutting processes are optional:
1) Gradually positioning and cutting.
Features: high precision.
2) Recognition followed by cutting: recognition of the whole layout and batch cutting.
Features: high efficiency and fast speed.

Q3.When I got Gbos cutting machine, I don't know how to use it. What should I do?
1)We will send you the video and manual with the laser machine.
2)If you still have some doubts, please contact us via Telephone / Skype / Email / Face book / Website, will answer you within 8 hours.
3)If necessary, we will dispatch the technician for in-house service (Installation & Training).

Q4: What's the warranty on the laser cutting machine?
1) Machine has warranty for 1 year, starting from the delivery date (subject to date on nameplate).
2) RF laser generator warranty for 12 months.
3) No warranty in case of damage due to improper handling.
4) No warranty for consumable parts (such as optical lens, focus lens and reflecting mirror).
5) Freight cost of replacement parts covered by the buyer.


Any problem, please do not hesitate to contact us, we will service to you at 7×24 hours.
